Villa Green Vista

Structure

R.C.C framed structure wit h 200mm concret e block walls using first quality materials, designed for seismic resistance

Joineries

Main door : Te ak wood frames with OST flush doo r, f r ont side varnished shutter, back side painted with branded locks.

Other doors: Hard wood / Sal wood frame with flush door shutter painted on both the sides.

Flooring

Johnson or equivalent make vitrified tile flooring in floor area of the huose i.e. living, dining , bedrooms, kitchen and walkways.

Balconies and sit-outs would be laid with ceramic Tiles or terracotta finished tiles. Glazed ceramic tiles will be fitted in toilet walls and anti-skid tiles would be laid in toilet floor and service areas. Toilet walls shall be finished with glazed tiles upto a height of 7' feet on walls.

Windows

UPVC w i n d o w s wi l l be fixed with MS Grills and 4mm clea r glass or pinhead glass. Suitable tower bolts and hinges shall also be fixed

Electrical

Using ISI quality copper cables wiring through PVC conduits concealed in walls and ceiling .

Electrical Points :

Fan point Light point 15 – AMP point 5 – A MP point TV & T e l . Foye r - 1 - L i vin g 1 2 - 2 1 each Dinin g 1 1 1 - Fridge 1 - Master Bedroom 12A/ C 2 1 each Other Bedrooms 12 A/C1 - Kitchen-1-1 - Mixie-Utility-11 - Grinder 1 Washing machine- Bathrooms-11 (Geys e r)1 - E x h aust - Three phrase connection with independent meter .

Wiring

Poly cabor equivalent

Switches

Modular plate switches (Anchor Roma or Siemens or equivalent make), MCB (Miniature Circuit Breaker )

(Standard or Havel's) and ELCB (Earth Leakage Circuit Breaker) systems, intercom facilities,

Kitchen

The cooking platform shall be fixed with colored granite and glazed tiles for a height o f 2' feet above the counter shall be provided. Suitable double bowl stainless steel sink shall also be fixed in the kitchen. Two tier RCC racks shall be fixed for storage below the cooking platform.

Plumbing & Sanitary

FInolex or equivalent high quality concealed pipe lines for hassle free water supply shall be fixed.

Branded fixtures i.e. Par rywar e or H ind ware shall be use d an d t oil ets shall be fitted with European Water Closet (EWC) and JAGUAR or equivalent quality C .P fittings . Suitable point s for fixing of hot water geysers and other gadgets shall be provided.

Wall Finishes

Internal walls will be finished with cement mortar and final finish with application of Putty, over one coat of primer and two coats of acrylic emulsion paint using vibrant colors. External walls shall be painted with Waterproof Cement paint
