DAC House of Palisade

STRUCTURE

• RCC Framed Structure and AAC blocks used for External/Internal walls.

• Earth Quake Resistant Structure to adhere to Seismic Zone III.

• Anti-Termite Treatments wherever applicable during Construction Stage.

TILES

• All tiles will be from SOMANY / KAJARIA or equivalent make.

• Living, Dining and Bedrooms- 800MM x 800MM vitrified tiles with spacers.

• Master Bedroom- 200MM x 1000MM wooden pattern vitrified tiles with spacers.

• Toilets, Balconies & Utility area- Antiskid ceramic tiles with spacers.

• Door thresholds will be finished with granite.

• Terrace – Weather proof tiles and 400MM x 400MM Stone pattern vitrified tiles with spacers in Party Terrace.

• Entrance verandah and Staircase- Granite flooring.

• Car parking – Parking Tiles/Kota/Shahabad or equivalent.

• All tiles will be from SOMANY / KAJARIA or equivalent make.

• Toilet– 2’ x 1’ ceramic wall tiles up to 8 feet height from the floor level.

• Utility areas– 2’ x 1’ceramic tiles.

• All windows sill level to be finished with granite.

KITCHEN

• 800MM x 800MM Vitrified tile flooring from SOMANY / KAJARIA or equivalent make.

• Open Kitchen (Counter top, wall dado, sink & sink faucets -not part of standard specifications.)

• Provision for water purifier & sink water point will be provided.

DOORS, WINDOWS, VENTILATORS

• MAIN DOOR (3'6” x 8'0”) 8 FEET HEIGHT, frame is made of African Teakwood with bottom threshold and architraves on both sides finished with PU polish. 40mm thick shutter finished with Veneer on both Sides and PU polished. Designer hardware of DORSET/YALE or equivalent make.

• BEDROOM DOOR (3'0” x 7'0”) 7 FEET HEIGHT, frame is made of African Teakwood and architraves on both sides finished with PU polish. 40mm thick shutter finished with Veneer on both Sides and PU polished. Designer hardware of DORSET/YALE or equivalent make.

• TOILET DOOR (2'6” x 7'0”) 7 FEET HEIGHT, frame is made of African Teakwood and architraves on both sides finished with PU polish. 40mm thick shutter finished with Veneer and PU polish on one side and laminate on other side. Designer hardware of DORSET/YALE or equivalent make.

• Aluminum French doors with sliding shutter will be from YKK or equivalent make.

• Aluminum Windows with sliding shutters for all windows will be from YKK or equivalent make. Grills will be provided.

• Aluminum Ventilators with pin headed glass along with Exhaust fan provision will be from YKK or equivalent make.

PAINTING FINISHES

• All internal walls will be finished with 2 coats of smooth putty, 1 coat of primer and 2 coats of Premium emulsion paint of NIPPON/ASIAN or equivalent make.

• All external walls will be finished with Texture, 1 coat of primer and 2 coats of weather proof emulsion paint of NIPPON/ASIAN or equivalent make.

• Ceilings will be finished with 2 coats of smooth putty, 1 coat of primer and 2 coats of Tractor Emulsion NIPPON/ASIAN or equivalent make.

• MS Railing for Staircase and Balcony finished with Enamel paint (Satin finish) aesthetically designed & fixed to wall.

ELECTRICAL FIXTURES / FITTINGS

• Three-phase power supply with concealed wiring will be provided.

• Separate meter will be provided for each villa, and the main board will be located outside the villa at the suitable place suggested by architects.

• All switches will be of HAVELLS /SCHNEIDER or equivalent make.

• Cables & wiring will be of HAVELLS/ANCHOR/POLY CAB or equivalent make.

• SPLIT A/C provision with electrification will be provided in Living room, dining and in all bedrooms.

• 15A plug points will be provided for Refrigerator, Washing machine, Micro-oven and Hob.

• 15A plug points will be provided for Geyser in all toilets.

• 5A socket for chimney will be provided in kitchen and Exhaust fan point in all toilets.

• Provision for Inverter with electrification in villas will be provided.

• Manual phase change over will be provided.

• TV points will be provided in Living and in all bedrooms and Telephone/Internet point in Living & Master bedroom.

• USB charging port in switch boards will be provided in Living and in all bedrooms.

• Video door phone will be provided for each villa.

PLUMBING & SANITARY

• All sanitary ware in ceramic of superior brands like KOHLER/GROHE or equivalent will be provided.

• EWC (Wall mounted closet) with health faucet of superior brand like KOHLER/GROHE or equivalent will be provided.

• High quality concealed flush cistern of GEBERIT or equivalent make for WCs.

• Washbasin and Granite counter washbasin of superior brand like KOHLER/GROHE or equivalent will be provided in toilets.

• CP fittings of superior brand like KOHLER/GROHE or equivalent will be provided.

• Single lever HI – FLOW concealed divertor of KOHLER/GROHE or equivalent makes of hot & cold mixer with overhead shower will be provided in the toilets.

• Thermostat concealed divertor of KOHLER/GROHE or equivalent makes with overhead rain shower along with Nozzle body spray will be provided in Master bedroom toilet.

• Hand shower will be provided in toilets.

• CPVC/UPVC pipelines/ PVC Soil waste lines/ sewage pipelines and Rainwater lines of a quality ISI brands like ASTRAL/SUPREME/PRINCE or Equivalent will be provided.

• Tap point in Terrace Area & car parking.

• Septic tank, Rain Water Harvesting will be provided.
