Casagrand Platinum

STRUCTURE

Structural System : RCC Framed Structure designed for seismic compliant (Zone 3),

Masonry : 200mm for external walls & 100mm for internal walls.

Floor- Floor height (incl. slab) : Will be maintained at 3050mm.

ATT : Anti–termite treatment will be done.

WALL FINISH

Internal walls : Finished with 2 coats of putty, 1 coat of primer & 2 coats of Premium emulsion.

Ceiling : Finished with 2 coats of putty, 1 coat of primer & 2 coats of Tractor emulsion.

Exterior walls : Exterior faces of the building finished with 1 coat of primer & 2 coats of exterior Emulsion paint with color as per architect design.

Bathroom : Ceramic tile up to 2250mm height of size 300×600mm.

Kitchen : Ceramic wall tile of size 600×600mm for a height of 600mm above the counter top finished level.

FLOOR FINISH WITH SKIRTING

Living, Lounge Dining, Bedrooms & Kitchen : Vitrified tiles of size 1200 x 600mm.

Bathrooms : Anti-skid ceramic tiles of size 300x300mm.

Staircase : Granite flooring for staircase will be provided.

Open Terrace (first floor) & Balcony : Anti-skid Vitrified tiles of size 600 x 600mm.

Landscape Deck : Shahabad / Kota stone finish.

Terrace : Pressed tiles finish.

Car parking : Shahabad / Kota stone finish.

KITCHEN & DINING

Kitchen : Platform will be finished with granite slab of 600mm wide at height of 850mm from the finished floor level.

Electrical point : For chimney & water purifier

CP fitting : Kohler / American Standard/ Equivalent will be provided.

Sink : Stainless Steel sink with drain board and pull-out sink faucet will be provided.

BALCONY / PRITVATE OPEN TERRACE AND STAIRCASE

Handrail : MS handrail as per architect’s design with enamel paint finish.

BATHROOMS

Sanitary fixture : Kohler / American Standard/ Equivalent.

CP fittings : Kohler / American Standard/ Equivalent.

Bed-1 Bathroom : Wall mounted WC with cistern, Health faucet, Rain Shower with hand shower, glass partition & counter mount wash basin.

Other Bathrooms : Wall mounted WC with cistern, Health faucet, Single lever diverter with overhead shower & Counter mount wash basin.

ELECTRICAL POINTS & PLUMBING POINTS

Power Supply : 3 PHASE power supply connection.

Safety device : MCB & ELCB (Earth leakage Circuit breaker).

Switches & sockets : Modular box & modular switches & sockets of Schneider / equivalent.

Wires : Fire Retardant Low Smoke (FRLS) copper wire of IS brand Polycab / equivalent.

TV : Point in Living & Bed-1 and provision in other bedrooms & Lounge.

Telephone : Point in Living & Bed-1

Data : Point in Living and provision in Lounge.

Split- air conditioner : Point will be provided in Living, Dining, Lounge & All bedrooms.

Exhaust fan : Point will be given in all bathrooms.

Geyser : Geyser point will be provided in all bathrooms.

Villa Back-up : Inverter provision for all room fan and light points.

VDP : Video door Phone will be provided in the entrance – Main door.

Mobile Charging Pod : Mobile charging pod in Bed- 1 & living area.

Bluetooth Speaker : Blue tooth speaker will be provided in the kitchen.

5amp Socket (Outdoor) : 5amp socket will be provided in the ground floor landscape deck and in any one open terrace in first floor.

HOB point : Point provided in the kitchen.

Tap : Provided in the outdoor deck.

Distance from Airport, Railway Station & Bus Stand

Chennai International Airport - 20.5 km, 32 min

Urapakkam Railway Station - 8.4 km, 12 min

Perungalathur Railway Station - 9 km, 14 min
