Casagrand Zaiden

STRUCTURAL

Structural System : RCC Framed Structure designed for seismic compliant (Zone 2)

Masonry :200mm for external walls & 100mm for internal walls

Floor- Floor height (incl. slab): Will be maintained at 3000mm

ATT: Anti–termite treatment will be done

WALL FINISH

Internal walls: Finished with 2 coats of putty, 1 coat of primer & 2 coats of emulsion.

Ceiling: Finished with 2 coats of putty, 1 coat of primer & 2 coats of emulsion

Exterior walls: Finished with 1 coat of primer & 2 coats of exterior emulsion paint with color as per architect’s design intent

Bathroom: Ceramic Tile up to false ceiling height of size 300x600mm & above false ceiling will be finished with a coat of primer

Kitchen: Ceramic wall tile of size 600x600mm for a height of 600mm above the counter top finished level

Toilet ceiling: Grid type false ceiling

FLOOR FINISH WITH SKIRTING

Main flooring: Vitrified tiles of size 600mm x 1200mm

Balcony: Anti-skid ceramic tiles of size 600mm x 600mm

Private open terrace (if applicable): Pressed tiles finish

KITCHEN & DINING

Kitchen: Platform will be finished with granite slab of 600mm wide at height of 850mm from the finished floor level

Electrical point: For chimney, hob & water purifier

CP fitting: Kohler / American standard /Equivalent

Sink : Single bowl SS sink with drain boar

Dining: Counter top washbasin will be provided wherever applicable

JOINERY

Main door: Good quality door of size 1050 x 2100mm with veneer finish and designer shutter

Ironmongeries like Digital Door lock of Yale or equivalent, tower bolts, door viewer, safety latch, magnetic door catcher, etc.

Bedroom doors :Good quality door of size 900 x 2100mm with laminate finish

Ironmongeries like Godrej or equivalent lock, door stopper, door bush, tower bolt, etc.,

Bathroom doors: Good quality door of size 750 x 2100mm with laminate finish and water proofing on inner side

Ironmongeries like thumb turn lock of Godrej/equivalent without key, door bush, etc

Windows: Aluminum windows with sliding shutters & plain glass

French doors: Aluminum doors with sliding shutters & toughened glass

Ventilators: Aluminum ventilators of fixed/ open-able shutter for ODU access (wherever applicable)

BALCONY

Handrail: MS handrail as per architect’s design

Cloth Drying Provision: Provided in balcony

BATHROOMS

CP fittings & sanitary fixture: Kohler / American standard / Equivalent

All Bathrooms: Wall mounted WC with cistern, Health faucet, Single lever diverter, Rain shower with a counter top wash basin

ELECTRICAL POINTS

Power Supply: Single Phase power supply connection for 2BHK Three phase power supply connection for 3BHK

Safety device: RCCB (Residual Current Circuit breaker)

Switches & sockets: Modular box, modular switches & sockets of good quality IS brand

Wires: Fire Retardant Low Smoke (FRLS) copper wire of good quality IS brand

TV: Point in Living & one of the bedrooms

Data & USB: Point in Living

Split- air conditioner: Points in Living and one of the bedrooms Provision in other bedrooms

Foot Lamp: Provision in all bedrooms

Exhaust fan: Point in all bathrooms

Geyser: Point in one of the bathrooms and Provision in all bathrooms

Back-up:400W for 2BHK & 500W for 3BHK

SPECIFICATION COMMON TO BUILDING COMPLEX

Lift: Elevators of 10 passengers automatic lift will be provided

Back – up:100% Power backup for common amenities such as Clubhouse, Lifts, STP, WTP & selective common area lighting

Owner’s Directory: Apartment owner name will be provided in ground Level

Lift fascia: Granite / equivalent cladding

Lift Lobby: Granite flooring @ ground level

Staircase floor :Granite flooring

Staircase handrail: MS handrail with enamel paint finish

Terrace floor: Pressed tile flooring

Terrace doors: Good quality FRP door of size 900x2100mm with paint finish

Ironmongeries like thumb turn lock of Godrej/ equivalent without key, door bush, automatic door closer, etc.,

OUTDOOR FEATURES

Water storage: Centralized UG sump with WTP (Min. requirement as per water test report)

Rain water harvesting: Rain water harvesting system as per site requirement

STP: Centralized Sewage Treatment plant

Safety: CCTV surveillance cameras will be provided all round the building at pivotal locations in ground level

Walkway: Walkway spaces well defined as per landscape’s design inte

Security: Security booth will be provided at the entrance

Compound wall: Site perimeter fenced by compound wall with entry gates

Landscape: Suitable landscape at appropriate places in the project as per design intent

Driveway: Convex mirror for safe turning in driveway in / out

External Driveway :Interlocking paver block/equivalent flooring with demarcated driveway as per landscape’s design intent
