Casagrand Meridian

STRUCTURE

Structural System : RCC wall structure (MIVAN) designed for seismic compliant(Zone – 2)

RCC Wall : 160mm for external walls & 160/100mm for internal walls (as per design intent) Floor- Floor height (incl. slab) : Will be maintained at 2980mm

ATT : Anti–termite treatment will be done

WALL FINISH

Internal walls : Finished with 2 coats of putty, 1 coat of primer & 2 coats of emulsion

Ceiling : Finished with 2 coats of putty, 1 coat of primer & 2 coats of emulsion

Exterior walls : Exterior faces of the building finished with 1 coat of primer & 2 coats of exterior Emulsion paint with color as per architect’s design intent

Bathroom : Ceramic Tile up to false ceiling height of size 300x600mm & above false ceiling will be finished with a coat of primer

Kitchen : Ceramic wall tile of size 600mm x 600mm for a height of 600mm above the counter top finished level. Toilet ceiling : Grid type false ceiling

FLOOR FINISH WITH SKIRTING

Foyer, Living, Dining, Bedrooms, Kitchen & Utility : Vitrified tiles of size 1200mm x 600mm

Bathroom : Anti-skid ceramic tiles of size 300mm x 300mm

Balcony : Anti-skid ceramic tiles of size 600mm x 600mm

Private Open Terrace (if applicable) : Pressed tiles finish

KITCHEN & DINING

Kitchen : Platform will be finished with granite slab of 600mm wide at height of 800mm from the finished floor level

Electrical point : For chimney & water purifier

CP fitting : Futura / American Standard /equivalent will be provided

Sink : Single bowl SS sink with drain board with Multi feature pull-out sink faucet

Dining : Counter top washbasin will be provided

BALCONY

Handrail : Glass handrail for Balcony as per elevation. Cloth Drying Provision : Cloth drying hanger provided in balcony.

JOINERY

Main door : Good quality frame with double side veneer finish shutter of size1050 x 2100mm with Decorative panel

Ironmongeries like Digital door lock, tower bolts, door viewer, safety latch, magnetic door catcher, etc.,

Bedroom doors : Good quality door frame with double side Laminate finish door of size 900 x 2100mm Ironmongeries like Godrej or equivalent lock, door bush, tower bolt, etc.,

Bathroom doors : Good quality door frame with double side Laminate finish door of Size 750 x 2100mm with water proofing on inner side

Ironmongeries like thumb turn lock of Godrej / equivalent without key, door bush, etc.,,/p> b. WINDOWS

Windows : Aluminum windows with sliding shutters & plain glass

French doors : Aluminum doors with sliding shutters & toughened glass

Ventilators : Aluminum ventilators of fixed / open-able shutter for ODU access (wherever applicable)

ELECTRICAL POINTS

Power Supply : 3 phase power supply connection

Safety device : MCB & ELCB (Earth leakage Circuit breaker)

Switches & sockets : Modular box & modular switches & sockets of good quality IS brand

Wires : Fire Retardant Low Smoke (FRLS) copper wire of good quality IS brand

Mobile charging dock : Provided in living

Hob Point : Point provided in the kitchen

TV : Point in Living & one of the bedrooms and Provision in other bedrooms

Telephone : Provision in Living & one of the bedrooms

Data : Provision in Living & one of the bedrooms

Split- air conditioner : Points in all bedrooms and provision in Living / Dining

Exhaust fan : Point in all bathrooms

Geyser : Point in all bathrooms

Back-up : 600W for 2BHK & 750W for 3BHK

COMMON FEATURES

Lift : Elevators of 10 passengers automatic lift will be provided

Back – up : 100% Power backup for common amenities such as Clubhouse, Lifts, STP,WTP & selective common area lighting

Name board : Apartment owner name will be provided in ground Level

Lift fascia : Granite / equivalent cladding

Lift Lobby : Granite flooring @ ground level & Tile flooring @ other levels

Staircase floor : Granite flooring

Staircase handrail : MS handrail with enamel paint finish

Terrace floor : Pressed tile flooring

OUTDOOR FEATURES

Water storage : Centralized UG sump with WTP (Min. requirement as per water test report)

Rain water harvesting : Rain water harvesting system as per site requirement

STP : Centralized Sewage Treatment plant

Safety : CCTV surveillance cameras will be provided all round the building at pivotal Locations in ground level

Well defined walkway : Walkway spaces well defined as per landscape’s design intent

Security : Security booth will be provided at the entrance/exit

Compound wall : Site perimeter fenced by compound wall with entry gates for a height of 1800mm as per design intent

Landscape : Suitable landscape at appropriate places in the project as per design intent

Driveway : Convex mirror for safe turning in driveway in / out

Internal Driveway : Interlocking paver block/equivalent flooring with demarcated driveway as per landscape’s design intent

SCHOOL

Cambridge School 9min

Samuel Public School 7min

St Antony Public School 3min

New indus valley Residential School 2min

Elixir International School 7min
